CARDIAC MAGNETIC RESONANCE IMAGING IN DIFFERENTIAL DIAGNOSTICS OF ACUTE CORONARY SYNDROME IN PATIENTS WITH NON-OBSTRUCTION CORONARY ATHEROSCLEROSIS

Aim. To investigate on the nosological structure of acute coronary syndrome (ACS) in patients with non-obstruction coronary atherosclerosis (NOCA) before and after magnetic resonance imaging (MRI) of the heart.

Material and methods. A non-randomized, open, controlled study (NCT02655718). The patients included, with ACS, older than 18 y.o., with NOCA (intact coronary arteries or stenosis ≤50%) confirmed by invasive coronary arteriography (ICAG). Patients with previous revascularization were not included.

Results. In the year 2016, to emergency cardiology department (ECD) 913 ACS patients admitted. In 44 (4,8%) the NOCA was found. Mean age 54±10,4 y.o., males 68%, and the groups with ACS with ST elevation (STEACS) and none (NSTEANS) were comparable by clinical and anamnestic parameters. Intact coronary arteries were visualized in 16 (53%), non-significant coronary atherosclerosis was diagnosed in 14 (32%), slower coronary flow — 22 (73%). By MRI with contrast, performed in 11±8 days (2-43 days) from ACS beginning, myocardial oedema was found in 18 (41%), hyperemia in 13 (30%) and fibrosis in 40 (91%); there were no changes in 1 patient.

Nosological structure of ACS in NOCA after MRI has been represented: by acute myocardial infarction (MI) in 24 (55%) cases, unstable angina (UA) — in 6 (14%), pseudocoronary myocarditis in 10 (23%), acute aorta dissection in 1 (2%), posttraumatic atherosclerosis in 1 (2%), congenital valve defect in 1 (2%), manifested Wolf-Parkinson-White (WPW) — in 1 (2%). In-hospital mortality was 2%. In comparison of ACS before and post MRI there was significant increase number of patients with myocarditis, by 20%.

Conclusion. The prevalence of ACS in NOCA is 4,8%, that is comparable to literature data. Patients with ACS and NOCA are heterogenic group with MI, UA, myocarditis, acute aorta dissection, posttraumatic atherosclerosis, congenital defects, WPW syndrome. In-hospital mortality was 2%. Comparing the structure of the diagnoses before and after MRI, there was significant increase of myocarditis patients number. A high accuracy of MRI was found for differential diagnostics of ACS in NOCA, which was 78%.

1. Agewall S, Beltrame JF, Reynolds HR, et al. ESC working group position paper on myocardial infarction with non-obstructive coronary arteries. http://eurheartj.oxfordjournals.org/content/early/2016/04/28/eurheartj.ehw149.

2. Pasupathy S, Tavella R, Beltrame JF. The What, When, Who, Why, How and Where of Myocardial Infarction With Non-Obstructive Coronary Arteries (MINOCA). Circulation, 2016; 80: 11-6.

3. Poku N, Noble S. Myocardial Infarction with non obstructive coronary arteries (MINOCA): a whole new ball game. Expert Review of Cardiovascular Therapy. DOI: 10.1080/14779072.2017.1266256.

4. Third Universal Definition of Myocardial Infarction. European Heart Journal, 2012; 33: 2551-67.

5. Gomboeva SB, Ryabov VV, Shelkovnikova ТА, et al. Case of pseudocoronary presentation of myocarditis with ST segment elevation, Russian Journal Cardiology 2016, 11 (139): 95-6. (In Russ.) (Гомбоева С.Б., Рябов В.В., Шелковникова Т.А., и др. Случай псевдокоронарного с элевацией сегмента ST на ЭКГ клинического течения миокардита, Российский кардиологический журнал, 2016, 11 (139): 95-6.

6. Rajiah P, Desai MY, Kwon D, et al. MR Imaging of Myocardial Infarction. Radiographics, 2013; 33 (5): 1383-412.

7. Roffi M, Patrono C, Collet JP, et al. ESC Guidelines for the management of acute coronary syndromes in patients presenting without persistent ST-segment elevation. European Heart Journal, 2015. https://www.escardio.org/static_file/Escardio/Guidelines/Publications/ACS/2015_NSTE-ACS%20Gles-Web-Addenda-ehv320.pdf.

8. Pilgrim TM, Wyss TR. Takotsubo cardiomyopathy or transient left ventricular apical ballooning syndrome: a systematic review. International Journal of Cardiology, 2008; 124 (3): 283-92.

9. Caforio AL, Pankuweit S, Arbustini E, et al. Current state of knowledge on aetiology, diagnosis, management, and therapy of myocarditis: a position statement of the European Society of Cardiology Working Group on Myocardial and Pericardial Diseases. European Heart Journal, 2013; 34 (33): 2636-48.

10. Sharif-Yakan A, Divchev D, Trautwein U, et al. The coronary slow flow phenomena or “cardiac syndrome Y”: A review. Reviews in Vascular Medicine, 2014; 2 (4): 118-22.

11. Herzog B, Greenwood J, Plein S. CMR Pocket Guide, 2013. https://www.escardio.org/static_file/Escardio/Subspecialty/EACVI/CMR-guide-2013.pdf

12. Stukalova OV, Gupalo EM, Mironova NA, et al. Role of contrast — enhanced cardiac MRI in diagnosing myocarditis with different clinical courses. Russian Heart Jounal, 2016; 15 (2): 133-40. (In Russ.) Стукалова О.В., Гупало Е.М., Миронова Н.А и др. Роль МРТ сердца с контрастированием в диагностике миокардита с различным клиническим течением. Сердце: журнал для практикующих врачей, 2016; 15 (2): 133-40.

13. Lurz P, Eitel I, Adam J, et al. Diagnostic Performance of CMR Imaging Compared With EMB in Patients With Suspected Myocarditis Cardivascular imaging, 2012, 5: 513-24.

14. Esposito A, Francone M, Faletti R. Lights and shadows of cardiac magnetic resonance imaging in acute myocarditis. Insights Imaging, 2016; 7: 99-110.
